Micro-Active Intelligent Management and Control System

Micro-Active Intelligent Management and Control System

Model: ATMIU-245G-02

Product Description

The micro-active intelligent management and control system is a multi-purpose device, it can support capture all MNO’s IMSI number and Wi-Fi & Bluetooth information around the equipment. which can be used as a stealth surveillance device in fixed scenes (such as offices, conference rooms, etc.), and as a small and flexible mobile device for wireless information searching in cars, hotels and other scenes.


The micro-active intelligent management and control system mainly uses wireless communication means, without affecting the user's normal communication, can collect all the operators IMSI number(including a variety of Internet of Things card) and surrounding WIFI information (including 2.4G/5.2G/5.8G), but also supports the collection of classic Bluetooth, Bluetooth Low Energy (BLE) information and accurately identify the model of cell phones such as Apple, Samsung, Huawei, and some of the secret filming and recording, eavesdropping and so on. tracking devices. It can also report the signal strength for the target cell phone and detect its direction distance. Forcibly disable the cell phone without affecting the non-target cell phone, blocking the illegal mobile communication equipment brought in.




The product is especially useful and easy to carry and operate. Applicable to offices, conference rooms, examination halls, government, military, prisons, public security, gas stations and other places where the use of mobile communication equipment is prohibited.

Feature

  • Mobile Phone Detection, support the IMSI collection function of mobile phones of all operator users, and shield and manage the 5G/4G/3G/2G signals of the white list users and off-account mobile phone users.

  • Wi-Fi Detection, support surrounding Wi-Fi information detection (including 2.4G/5.2G/5.8G).

  • Bluetooth Detection support surrounding Bluetooth and Bluetooth Low Energy (BLE) information detection and some of the secret filming and recording, eavesdropping device

  • Mobile Phone Communication Shielding, automatic communication shielding of illegal mobile phones, and timely blocking of communication services such as voice, text messages, and Internet access.

  • Communication System, support 5G/4G/3G/2G main frequency bands of all operators.

  • White List Function, white List users are allowed to keep all communication functions such as call, text message, and Internet access, and cut off all communication permissions of all off-account mobile phone users

  • Direction Detection and Signal Strength Report, support report the signal strength for the target cell phone and detect its direction distance.

  • Safe, Reliable and Easy to Operate, Easy to operate, hidden, portable, simple to operate, low power consumption, low noise and does not affect the operation of other electronic equipment in the premises.


Technical Specification

Items

Specifications

Working   Frequency Range

2G

B3(1800MHz)/B8(900MHz)

4G

B28(700MHz)/B20(800MHz)/B5(850MHz)/B8(900MHz)/

B3(1800MHz)/B33(TDD-1900MHz)/B1(2100MHz)/

B34(TDD-2100MHz)/B40(TDD-2300MHz)/B41(TDD-2500MHz)/

B38(TDD-2600MHz)/B7(2600MHz)

5G

N28(700MHz)/N41(2500MHz)/N77(3500MHz)/N79(4900MHz)

Wi-Fi

2.4G/5.2G/5.8G

Bluetooth

Normal Bluetooth / Bluetooth Low Energy (BLE)

System Standard

GSM /FDD-LTE/TDD-LTE/5GNR/Wi-Fi/BT

Operators

All Operators

Working Mode

Active

Capacity

Maximum 18 Carriers(2*2G+12*4G+4*5G)

Max Output Power

≤15dBm per Band

Receiving Sensitivity

≥-103dBm

Coverage Area

≤ 20m (Depends   on the Environment)

Synchronization

GPS/BD Synchronization; Air Interface   Synchronization

Power Consumption

≤ 36W

RF   Performance

Comply with 3GPP

Antenna

PCB Antenna Built In

Power   Supply

Powered by a Power Bank or Direct DC 5V Supply

Demission

175*226*38mm

Weight

1.5kg

Application

Indoor (IP30)
