| Coupling Level | 5dB | 6dB | 7dB | 8dB | 10dB | 12dB | 15dB | 20dB | 25dB | 30dB | 40dB |
| Frequency Range | 698~6000MHz(Customized) | ||||||||||
| Coupling Uniformity | ±0.8 | ±0.8 | ±0.8 | ±0.8 | ±1.0 | ±1.0 | ±1.0 | ±1.2 | ±1.2 | ±1.5 | ±1.5 |
| Insertion loss(dB) | ≤ 2.0 | ≤ 1.8 | ≤1.45 | ≤1.30 | ≤ 0.8 | ≤ 0.8 | ≤ 0.5 | ≤ 0.4 | ≤ 0.4 | ≤ 0.4 | ≤ 0.4 |
| VSWR | ≤ 1.3@698~2700MHz, ≤ 1.5@2700~6000MHz | ||||||||||
| Isolation(dB) | ≥ 25 | ≥ 26 | ≥ 27 | ≥ 28 | ≥ 30 | ≥ 32 | ≥ 35 | ≥ 40 | ≥ 45 | ≥ 50 | ≥60 |
| PIM3 | ≤-160dBc @2×43dBm | ||||||||||
| Impedance | 50Ω | ||||||||||
| Power Handling | 300 W(Avg.) | ||||||||||
| Operating Temperature | -25°C to +65°C | ||||||||||
| Relative Humidity | 5% ~ 95% | ||||||||||
| Application | Indoor or Outdoor(IP67) | ||||||||||
| Connector Type | 4.3-10 Female or Customized | ||||||||||
| Weight | ≤0.7kg | ||||||||||
| Dimensions | ≤163.2x63.4x32(mm) | ||||||||||
| Packing | ≤1 PCS/Box | ||||||||||
